Product model DEK-Q20
Explosion proof sign Exd Ⅱ CT6
Protection level IP66
Imaging device color 1/3 "SONY Super HAD CCD
Signal standard PAL
Resolution 700TVLIN
Video output 1.0Vp-p (75 Ω, composite video)
Automatic day and night switching (ICR automatic switching)
Minimum illumination color: 1.0Lux, black and white: 0LUX (infrared light on)
Signal to noise ratio ≥ 50dB
White balance automatic white balance
Internal/external synchronization (V-Lock)
Electronic shutter 1/1s to 1/10000s
Automatic gain control (AGC) automatic
AE control automatic
Specification of outlet hole G-1/2 "
EV compensation -10.5 to+10.5dC (1.5dB range)
Backlight compensation (BLC) on/off
Lens 8mm
Infrared distance of 20m
The infrared switch automatically turns on when the illumination is below 0Lux
Power supply voltage DC12V
Working current<1A
Power consumption ≤ 10W
Environmental temperature -25 ℃~+70 ℃
Atmospheric pressure: 80KPa~106KPa
Relative humidity ≤ 95% RH (+25 ℃)
Product material: stainless steel
External dimensions: ￥ 119mm x 102 mm (length)
Weight ≤ 2kg
