Exd Ⅱ CT6 Gb/Ex tD A20 T80 ℃
Explosion proof certificate number: CNEx17.0052X
Intelligent fire point detection function with multi-level fire point detection, efficient detection, reducing false alarms, doubling visible light linkage, and viewing surrounding conditions
Perceived intelligent rules support area intrusion, boundary crossing, entry/exit area detection
Excellent thermal imaging effect with a resolution of 384 x 288
Maximum temperature cross positioning, supporting 1 line temperature measurement, 10 frame temperature measurements, and 10 point temperature measurements, with 100 associated temperature measurement preset positions
Temperature measurement range: -40 ℃~550 ℃, temperature measurement accuracy: ± 2 degrees (or ± 2% of the range)
Temperature abnormal alarm
Precision motor drive, sensitive response, smooth operation, accuracy deviation less than 0.1 degrees, no image shake at any speed
? Supports power-off state memory function, automatically returning to the pan tilt and lens state before power-off after power-off
Support lightning protection, surge prevention, and surge prevention
Mechanical indicators
Material: stainless steel 316L
Protection level: IP68
Dimensions of the inner chamber of the protective cover for use: 220 (L) x 80 (W) x 70 (H) mm
Horizontal rotation: 360 °
Vertical rotation:+90 °~-90 °
Horizontal rotation speed: 0.1-40 °/S
Vertical rotation speed: 0.1-40 °/S
Unit weight: 32Kg
Transportation weight: 35Kg
Installation method: fixed bracket, base, column
Electrical indicators
Input voltage: 220VAC DC24V
Input voltage range: ± 10%
Working current: ＜ 500mA (220VAC) Power consumption: approximately 100W
Communication method: RS-485
Communication speed: adaptive
Communication protocol: PELCO-D/P ONVIF2.0
Infrared distance: 50, 80, 100 meters
Number of preset positions: 256
Pre positioning accuracy: ≤ 0.1 °
Electrical connection: 3-core cable connects to power supply, 2-core shielded cable connects to control signal, coaxial cable outputs video signal or RJ45
Infrared thermal imager
Detector type: non cooled focal plane micro thermal type
Pixel 384 x 288
Pixel spacing 17 μ M
Working wavelength 7.5-14 μ M
Thermal sensitivity ＜ 0.04 ℃ @ 30 ℃
Lens parameters
Lens types 19mm, 25mm, 35mm, 50mm, 75mm heat dissipation differential lenses
15mm, 25mm, 35mm, 50mm, 75mm electric lenses
Focal length 25mm/F=1
Field of view 24 ° x 18 °
Frame rate 50Hz
Focusing on electric, supporting autofocus
Clear imaging range of 0.3m~∞
Temperature measurement performance
Temperature measurement range -20 ℃~+150 ℃ (standard),+180 ℃~+600 ℃ (optional)
Temperature measurement accuracy of ± 2 ℃ or ± 2%, whichever is higher
Display enhancement automatic stretching, DDE digital image detail enhancement
The emissivity black background temperature calibration is automatically calibrated based on the input emissivity and background temperature,
Emissivity adjustable from 0.01 to 1
Filter or window transmittance correction automatically adjusts based on input transmittance
Atmospheric transmittance correction automatically calculates atmospheric transmittance and corrects temperature based on meteorological parameters
Real time display of high temperature point position and temperature through tracking the highest temperature
Color palette gray, colored, iron red
Electronic zoom 2x, 4x
Camera 2 2 million
20x 2.1 million 1/2.8 "CMOS ICR day and night network high-definition all-in-one machine
Sensor type: 1/2.8 "Progressive Scan CMOS
Signal system: PAL/NTSC
Day night conversion mode: ICR infrared filter type
Signal to noise ratio: greater than 52dB
Electronic shutter: 1/1 second~1/30000 second
Resolution:
50Hz: 25fps (1920x1080) 60Hz: 30fps (1920x1080)
50Hz: 25fps (1280x720) 60Hz: 30fps (1280x720)
Minimum illumination:
Color: 0.05Lux @ (F1.6, AGC ON)
Black and white: 0.01Lux @ (F1.6, AGC ON)
White balance: automatic 1/automatic 2/indoor/outdoor/manual/sodium lamp/fluorescent lamp
3D noise reduction: supported
Focal length: 4.7-94mm, 20x optical
Aperture: F1.6-F3.5
Horizontal viewing angle: 61.4-2.9 degrees (wide angle - far view)
Close up range: 10-1500mm (wide-angle telescope)
Multiplying speed: approximately 2.7 seconds (optical, wide-angle telescope)
Exposure mode: automatic exposure/aperture priority/shutter priority/manual exposure
Focus mode: automatic focus/one-time focus/manual focus
Wide dynamic: off/on, 4-level adjustable
Video compression standard: H.264/MJPEG
Compressed output bit rate: 32 Kbps~16Mbps
Image settings: saturation, brightness, and contrast can be adjusted through the client or IE browser
Storage function: supports micro SD
Intelligent alarm: movement detection, obstruction alarm, memory full, memory error
Supported protocols: TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, UPnP, SNMP, FTP, 802.1x, QoS, HTTPS, IPv6 (SIP, SRTP, optional)
Universal features: dual stream, heartbeat, password protection
Communication interface: 1 RJ45 10M/100M adaptive Ethernet port, 1 RS-485 interface
Interface protocols: ONVIF, PSIA, CGI
