Explosion proof signs Exd Ⅱ CT6/DIP A20 TA, T6
Electrical indicators
Input voltage 100V~240VAC
Working current ≤ 0.5A
Power consumption ≤ 35W
Electrical connection 2-core cable for power input coaxial cable for video signal output RJ45
Mechanical index material: stainless steel 304 or 316L
Protection level IP68
Window transparent component thickness 10mm
Window diameter 60mm
Weight/Transportation Weight 8Kg/10Kg
Number of outlet holes 2
Thread size of outlet hole G-3/4 "
Installation method: electric pan tilt, semi fixed pan tilt, fixed bracket
