Exd Ⅱ CT6 Gb/Ex tD A20 T80 ℃
Explosion proof starry infrared gun type camera
Explosion proof certificate number: CNEx16.3314X
Material: stainless steel 304 or 316L
Protection level: IP68
Window: Thickness 10mm
Window area: Φ 60mm
Installation method: semi fixed pan tilt and fixed bracket
Electrical indicators
Input voltage range: -25%~+10%
Working current: ≤ 1A
Power consumption: ≤ 30W
Infrared light projection distance: 50, 80, 100 meters
Infrared light projection angle: 30 °/60 °
Cold light projection angle: 30 °
Signal specifications
Video signal output: 1Vp-p ± 20% (75 Ω) RJ45
Product features:
High performance 2 megapixel 1/1.9 'CMOS
Equipped with 30x optical zoom, optical zoom f=6-180mm (F1.5 to 4.3)
The maximum resolution can reach 1980* 1080@60fps Clear image
Adopting full motion focusing, dynamic exposure, and dynamic balance algorithms with fully autonomous intellectual property rights
Supports 3D noise reduction, anti shake, fog penetration, ROI encoding and focusing, and privacy occlusion for 24 areas
Equipped with automatic aperture, electric shutter, and ICR filter switching functions to adapt to different monitoring environments
Applicable occasions
Suitable for large-scale warehouses, peripheral monitoring of residential areas, docks, parking lots, schools, stations, parks, and other large-scale monitoring places.
Product parameters
1/1.9 inch CMOS
Approximately 2.42 million pixels
≥ 1000TVL
1920 × 1080
Colorful silk 0.001Lux@F1.5 : ??: 0.0001Lux@F1.5
≥ 55dB
Mobile/Mobile/Tracking/Outdoor/Indoor/Outdoor Mobile/Sodium Lamp Mobile/Sodium Lamp
1/1 to 1/30000s
Dynamic ICR filter color conversion
6mm~180mm
Level: 61.2 o to 2.32 o (near to far focus)
10mm~1500mm (near to far focus)
30x
F1.5~F4.3
50Hz: 25fps (1920 x 1080), 50fps (1920 x 1080), 25fps (1280 x 960), 50fps (1280 x 960), 25fps (1280 x 720), 50fps (1280 x 720)
60Hz: 30fps (1920 x 1080), 60fps (1920 x 1080), 30fps (1280 x 960), 60fps (1280 x 960), 30fps (1280 x 720), 60fps (1280 x 720)
50Hz: 25fps (704 × 576), 25fps (352 × 288)
60Hz: 30fps (704 × 480), 30fps (352 × 240)
50Hz: 25fps (1920 x 1080), 25fps (1280 x 960), 25fps (1280 x 720), 25fps (704 x 576), 25fps (352 x 288)
60Hz: 30fps (1920 x 1080), 30fps (1280 x 960), 30fps (1280 x 720), 30fps (704 x 480), 30fps (352 x 240)
H. 265/H.264BaselineProfile/H.264MainProfile/H.264HighProfile/M-JPEG
G. 711a/G.711Mu/AAC/G.722/G.726/MPEG2-L2
IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
Supports open APIs for software integration, standard protocols (Onvif, CGI, GB/T28181), DH-SDK, and third-party management platform interfaces
Using IE7 or higher versions (including IE7) for music, Firefox, Apple, and other IE browsers
Up to 20 channels (total bandwidth 48M)
Authorized username and password, as well as MAC address binding; HTTPS encryption; IEEE 802.1x Network Access Control (User List)
Multi level user permission management
Network output/analog output
PELCOD/PELCOP protocol, DH-SD1 protocol, SONY VISCA protocol
RS485: Baud rate holding 96001920038400bps, VISCA 232: fixed baud rate 9600
Built in Micro-SD card slot, supports SD/SDHC/SDXC (up to 128G), can hold automatic recording/alarm recording, can hold continuous transmission after interruption, and recording is not lost
